首頁 / 產品中心 / 鏈條 / 不銹鋼鏈條 SUS304/316
Stainless Steel Link Chain SUS304/316
DIN766 Standard
Din Inside
length 		Inside
width 		Weight/m
mm mm mm kg
2 12 3.5 0.07
3 16 5 0.163
4 16 5 0.32
5 18.5 6 0.5
6 18.5 7.2 0.8
7 22 8.4 1.1
8 24 9.6 1.4
9 27 10.8 1.8
10 28 12 2.3
11 31 13.2 2.68
12 36 14.6 3.11
13 36 15.6 3.8
16 45 19.2 5.7


DIN763（DIN5685C） Standard
Din Inside
length 		Inside
width 		Weight/m
mm mm mm kg
2 22 4 0.061
2.5 24 5 0.1
3 26 6 0.15
3.5 28 7 0.2
4 32 8 0.27
4.5 34 9 0.35
5 35 10 0.43
6 42 12 0.63
7 49 14 0.86
8 52 16 101
9 59 18 1.14
10 65 20 1.75
13 82 26 2.95
16 100 32 4.45


DIN5685 Standard
Din Inside
length 		Inside
width 		Weight/m
mm mm mm kg
2 12 4 0.071
2.5 14 5 1.114
3 10 6 0.165
3.5 18 7 0.23
4 19 8 0.3
5 21 10 0.5
6 24 12 0.73
7 28 14 1
8 32 16 1.3
9 36 18 1.62
10 40 20 2.05
12 48 24 2.9
13 52 26 3.45


ASTM80 Standard
Din Inside
length 		Inside
width 		Weight/m
In mm mm mm kg
1/8 4 23 7 0.29
3/16 5.5 24 10.2 0.6
1/4 7 25.4 12.5 1.07
5/16 8.7 27.9 12.7 1.57
3/8 10 34.2 15.17 2.3
1/2 13.5 39.6 18.2 4
5/8 16.7 49 25.5 6.04


ASTM90 Standard
Din Inside
length 		Inside
width 		Weight/m
In mm mm mm kg
1/8 4 23 7 0.29
3/16 5.5 24 10.2 0.6
1/4 7 29.3 11 0.98
5/16 8 32.5 12.4 1.28
3/8 10 34.5 14 2.12
1/2 13 45.5 19.8 3.61
5/8 16 54 21.5 5.34
