G100 Eye Sling Hook with Latch(TH-1003)

Green painted.other colour is available as per request.

Working load limit permanently shown on the body.

Max proof load is 2.5 times of the working load limited.

Min.Breaking strength is 4 times of the W.L.L.

Size W.L.L B.L Dimension(mm) Weight
(t) (t) D E H Φ L kg/pc
6-10 1.4 5.6 10 18.5 21 20.5 111 0.32
8-10 2.5 10 11 25 27.5 25 137.5 0.6
10-10 4 16 16 28 33 34 171.5 1.2
13-10 6.7 26.8 19 38 43.5 43 219 2.2
16-10 10 40 4.5 44 50 50 260 3.5
20-10 16 64 27 52 56 55 298 7.15
22-10 19 76 29 66 62 60 330 11.5
26-10 26.5 106 35 73 75 70 367 14
32-10 39.3 157.2 39 87 89 66 427 17.5
