G100 Eyes Shortening Grap Hook(TH-1008)

Green painted.other colour is available as per request.

Working load limit permanently shown on the body.

Max proof load is 2.5 times of the working load limited.

Min.Breaking strength is 4 times of the W.L.L.

Size W.L.L B.L Dimension(mm) Weight
(t) (t) E Φ D M kg/pc
6-10 1.4 5.6 8 14.5 30.5 43.5 0.2
8-10 2.5 10 10.8 18 37 53 0.28
10-10 4 16 13.5 22.5 48.5 42 0.72
13-10 6.7 26.8 16.5 28 59 96 1.6
16-10 10 40 19.2 36 74 112.5 2.45
20-10 16 64 24 43.5 89.5 143 4.72
22-10 19 76 27 48.5 100.5 160.5 8.2
